MASSIVE, INNOVATIVE AND NETWORKED LIGHTING SOLUTIONS
Powerline light management
Existing electricity grids can be used by Powerline technology for establishing a data transmission network.
Light management radio settings from the office
The user-friendly interface enables configuring, analysing, controlling and monitoring of luminaires from an office. The associated software provides an overview of the complete lighting installation, thereby guaranteeing optimum maintenance planning. All data is transmitted in encrypted form to protect the system from unauthorised access. A PIN code provides further protection from third party access.
Your advantages with LiveLink Outdoor
Reduce costs
Protect the climate and the environment
Ensure operational efficiency
Design the infrastructure to be future-safe
Three possible light management solutions
| Sensor single solution | Self-regulating system | Web-based system | |
| Applications | Suitable for single, independent light points |
Suitable for smaller projects Industrial facilities, parking lots and minor roads |
Suitable for large installations Locations with high volume of traffic, main roads, residential and industrial areas |
| Benefits | System-independent single solution for individual light points |
Ideal for small isolated solutions Low-cost entry-level variant Protected, individual system Ideal for pilot installations |
Ideal for large installations Protected, individual system Data in real time, statistics and analysis options Control cabinet solution can be integrated |
| Functions |
Motion detection and dimming Configuration of dimming level |
Grouping of luminaires Individual configuration of each luminaire |
Grouping of luminaires Individual configuration of each luminaire Error message notifications Configuration, control and monitoring of luminaires |
Smart Outdoor
effective and environmentally friendly
- Networking via the LiveLink Outdoor lighting management system
- Luminaires were equipped with a sensor for presence detection
- Reduced energy consumption of the system "in idle state" due to individually selected dimming profiles
- Dimming to 50% of the basic brightness when nobody is in the detection range of the sensors
- Reduction of the base level to 10% during the night hours (22:00 - 05:00).
- If a person is detected by a presence sensor, the illuminance of the affected luminaire increases to 100% for 90 seconds
- Demand and accompanying lighting
- Communication /activation of two light points
