LC60 LED

Light lines in their most attractive form

The challenge

Trends in the office environment lead towards clean, integrated architectural elements, which also apply to the lighting. In addition to the appearance and flexibility of the configuration, the luminaire must provide perfect light where it is needed.

The solution

The LC60 is designed to work with diverse requirements and can adapt to most shapes. The mounting options, lengths, and accessories give adaptable solutions whilst never compromising on the quality of light, even lighting that supports human activity.

Connectivity

HCL

Energy-saving

Advantages with lighting design

The LC60 offers freedom of expression with versatility of design

  • Intelligent modules, each with a width of 60mm, are available in different module lengths with fully illuminated T, L and X-connectors
  • The light channel can be mounted horizontally or vertically, and turn corners on both axis

The light channel can be mounted horizontally or vertically, and turn corners on both axis

The LC60 light channel system shows full flexibility in terms of mounting, either with the trimless version as a recessed channel or with a trim for plasterboard ceiling apertures. The system is also available as a surface-mounted channel and a suspended version with an indirect light component for ceiling Illumination.

Benefits during installation

Commissioning – plug & play with Linect®

Incredibly quick: with the universal Linect® connection system, Creavo can be connected quickly and easily via plug & play. For maximum flexibility the luminaires can be installed either conventionally or via a plug-in connection. Connected luminaire concepts are implemented as continuous lines with a single power feed. The result: significant time savings when connecting.

Quality – premium material and excellent workmanship

When the going gets tough: high quality materials such as a robust sheet steel body facilitate handling. Thanks to precise workmanship, the luminaire can be mounted quickly and easily without pressing, squeezing or squeaking.

Networking – quickly done with LiveLink

With the TRILUX LiveLink light management system, luminaires can be quickly and easily networked and combined with sensors. In building areas without system ceilings, surface-mounted and suspended luminaires can be networked quickly thanks to LiveLink Wireless without laying DALI control lines – this saves time and money during installation.

Advantages in operation

Winning features – high efficiency and low operating overheads

With an efficiency of up to 150 lm/W and a service life of L90 50,000 h, Creavo ensures permanently low operating costs – with savings of up to 50 percent compared to conventional systems. Additional reductions in operating costs are also possible by combining with the LiveLink light management system.

Human Centric Lighting – for greater well-being in the workplace

Creavo is available as Active version for Human Centric Lighting, thus bringing "natural daylight" into the office. This can increase the well-being of employees and strengthen the biological rhythm when working in closed rooms without sunlight.

IoT harbour – space for the future

Fit for the future: the IoT harbour offers space for a sensor, beacon or emergency-control LED as standard. The sensor for daylight and presence control in combination with the LiveLink light management system enables the operating costs to be minimised. The beacon for Location Based Services can be used e.g. for navigation in the building or for room booking. The emergency light variants provide light in emergencies. Upon request, the IoT Harbour, thanks to its interface-based design, offers users the option of easily integrating additional sensors. This creates maximum future security.

One product family with many variants

Anything goes: thanks to a broad portfolio of sizes, optics and mounting methods, all lighting tasks in offices and education can be solved with one luminaire range – e.g. with a wall-washer for panel lighting in the same luminaire design.

Special light comfort

The directional light system with ConVision® technology features outstanding quality of light – with noticeably reduced glare and fewer disturbing multiple shadows.

Design

The light chambers are available as standard in three different colours – optionally in white, silver or matt black. The light chambers as well as the sheet steel can also be individually designed upon request.

High efficiency, low costs

Due to its high efficiency (up to 150 lm/W) and long service life (L90 50,000 h), Creavo is particularly attractive economically – with 50 percent lower energy consumption compared to conventional old systems.

Refurbishment

Creavo is available with lumen packages analogous to the common T5/T8 solutions. In combination with the suitable module dimensions of conventional solutions, particularly simple one-to-one refurbishment is possible.

Networking

Luminaires can be quickly and easily networked with the TRILUX LiveLink light management system. In building areas without DALI control lines, the luminaires can be networked via LiveLink Wireless.

Future security

Creavo has an IoT harbour equipped as standard with a sensor for daylight and presence sensor or beacon for location-based services. Upon request, the IoT harbour, thanks to its interface-based design, offers users the option of integrating additional sensors. Separate emergency light variants provide light in the event of an emergency.

Downloads and brochures

Download

Technical features

6 mounting options surface, recessed, suspended in both direct and direct/indirect, plus a wall mounted option with choice of directions
4 construction shapes use accessories to create a cross, t-shape, and changes of direction either vertically or horizontally
2 light colours a choice of 3,000 or 4,000 K
2 optical diffuser options finely structured translucent polycarbonate or prismatic CDP
4 Lengths 564 mm, 1,124 mm, 1,404 mm, 2,244 mm
3 Luminaire colour white, black, silver
