Opendo LED

Advanced lighting

The challenge

  1. Efficient refurbishment of obsolete conventional luminaire systems
  2. Tight cost framework with high demands on quality and efficiency
  3. Specific structural and photometric requirements
  4. New tasks, such as monitoring air quality

The solution

  1. Customised solutions for all areas in schools and offices
  2. High-quality planar light across the entire width of the luminaire
  3. Refurbishment and maintenance-friendly design
  4. Turnkey solutions with integrated functional modules, e.g. CO2 sensors

Light and luminaire design

Full-surface light emission area: Learning and working can be a beautiful experience, in terms of light and luminaire design, anyway: Opendo LED brings high-quality planar light and a new functional/attractive aesthetic to the education and office sector. One of its highlights is the light emission surface, which extends over the entire width of the luminaire and blends into an accentuated light edge around the sides.

Air quality in check at all times

Added value with CO2 sensors and more. Learning and working can be a beautiful experience, in terms of light and luminaire design, anyway: Opendo LED brings high-quality planar light and a new functional/attractive aesthetic to the education and office sector. One of its highlights is the light emission surface in the surface-mounted and suspended luminaire, which extends over the entire width of the luminaire and blends into an accentuated light edge around the sides.. In the recessed luminaire, the light emission surface is flush with the luminaire housing and integrates seamlessly into the ceiling system.

Light and luminaire design

Full-surface light emission area: Learning and working can be a beautiful experience, in terms of light and luminaire design, anyway: Opendo LED brings high-quality planar light and a new functional/attractive aesthetic to the education and office sector. One of its highlights is the light emission surface, which extends over the entire width of the luminaire and blends into an accentuated light edge around the sides.

Air quality in check at all times

Added value with CO2 sensors and more. Learning and working can be a beautiful experience, in terms of light and luminaire design, anyway: Opendo LED brings high-quality planar light and a new functional/attractive aesthetic to the education and office sector. One of its highlights is the light emission surface in the surface-mounted and suspended luminaire, which extends over the entire width of the luminaire and blends into an accentuated light edge around the sides.. In the recessed luminaire, the light emission surface is flush with the luminaire housing and integrates seamlessly into the ceiling system.

The continuous line

Top marks for education: Be it as a continuous line or individual luminaire, as a recessed, as a surface-mounted or suspended luminaire, with symmetric or asymmetric light distribution – Opendo LED is up for anything. Especially convenient: Thanks to through-wiring via a simple accessory, the Opendo LED continuous line requires only a single feed, making installation quick and simple. The result: standard-compliant light with maximum efficiency.

The continuous line

Top marks for education: Be it as a continuous line or individual luminaire, as a recessed, as a surface-mounted or suspended luminaire, with symmetric or asymmetric light distribution – Opendo LED is up for anything. Especially convenient: Thanks to through-wiring via a simple accessory, the Opendo LED continuous line requires only a single feed, making installation quick and simple. The result: standard-compliant light with maximum efficiency.

Features

  1. Customised solutions for schools and offices: Two optics with symmetric light distribution for standard-compliant basic lighting and asymmetric light distribution for homogeneous blackboard lighting
  2. Custom-fit installation options: Installation optionally as a recessed, as a surface-mounted or suspended luminaire, as suspended or surface-mounted luminaire, as individual luminaire or continuous line
  3. Continuous line with through-wiring: Rapid continuous line installation thanks to through-wiring with only one infeed optionally for suspended or surface-mounted luminaires.
  4. One design for all areas: Straightforward, modern design that blends harmoniously into any environment and facilitates holistic solutions across applications, for instance in classrooms, common rooms, meeting rooms, single and twin offices, large work rooms and entrance areas
  5. HCL – dynamic sunlight quality : Human Centric Lighting strengthens the biorhythm and increases well-being.
  1. Networking and light management: simple networking, optionally via radio (wireless) if no DALI control lines are available
  2. State-of-the-art sensors: modules with integrated daylight and presence sensors increase efficiency. CO2 sensors measure air quality
  3. Revisable control gear: simple replacement of the control gear unit for simple maintenance and more sustainability
  4. Emergency light system with integrated battery: All inclusive: Opendo LED is available as a version with emergency light function, integrated battery and changeover relay.
  5. Refurbishment-optimised design: Luminaire width, feed points, drill holes or installation dimensions, luminous fluxes as well as accessories– everything is designed for a quick 1:1 refurbishment of existing luminaires (surface-mounted and suspended luminaire 504, 505; recessed Enterio, 3501, 3601...)

Design

Modern schools and offices require lighting solutions that take into account not only business and functional requirements but also aesthetic needs. This is why we developed Opendo LED. It scores points equally with its light quality and its design. Its light emission surface over the entire width of the luminaire and the lateral light edge of the surface-mounted and suspended luminaires or the seamless integration of the light emission in the luminaire housing of the recessed luminaires are unique features. Thanks to custom-fit photometrics for every application area, Opendo LED can be used to realise holistic solutions from a single cast.

Applications

School

The educational sector places the highest demands on lighting technology and quality, sometimes with complex structural conditions on site. Perfectly adjusted: Thanks to customised light distributions – such as asymmetric blackboard lighting – Opendo LED meets all the requirements for future-proof and sustainable school lighting.

Office

Quality of light and design have a particular influence on the working atmosphere in the office. Opendo LED is impressive in both areas – with customised planar light and an unmistakably modern design. Sensor systems, light management and integrated emergency light? Anything is possible.

Lighting Design

Schools and offices place high standard requirements on lighting, for instance UGR19 and suitability for DSE work or asymmetric blackboard lighting. Customised solutions for education and offices make it possible to cover all requirements with one single luminaire. This simplifies planning and facilitates integrated solutions in a uniform design.

Installation

High material quality, sophisticated installation features and a clever refurbishment concept make installation particularly simple. Continuous lines require only a single infeed thanks to optional through-wiring. This makes installation particularly effortless.

Operation

High efficiency, low operating costs and excellent quality of light are just some of Opendo LED’s strengths. The luminaire can be flexibly equipped with sensors, in particular a CO2 sensor for measuring air quality. Especially sustainable: The control gear can be replaced without effort in the event of maintenance.

Energy consumption

Numerous national and regional aid programmes support the long overdue LED lighting refurbishment in schools, for instance the BMU funding measures. Opendo LED meets all the energy efficiency and sustainability requirements associated with funding.

Read more

Energy consumption in kWh per year

Technical data

Lengths Surface-mounted/Suspended
D1 / H1: 160x1200
D2 / H2: 160x1500
RecessedM36: 185 x 1200
M37: 185 x 1250
M38: 185 x 1500
M39: 185 x 1550
Luminaire luminous flux Surface-mounted/ Recessed luminaire 1200mm: 3600lm
Surfaced-mounted/ Recessed luminaire 1500mm: 4200lm / 4700lm
Suspsended 1200mm: 5300lm
Suspended 1500mm: 6400lm
Efficiency up to 130 lm/W
Service life L80 at 50,000 h
Colour temperature 830 / 840
Protection rating IP20
Housing Sheet steel luminaire body
Approval marks CE, ENEC (pending)
LMS Light management with LiveLink including Wireless
Sensor system CO₂-sensors/daylight and presence sensors
Emergency light Individual emergency light battery 3 h
Changeober relay (recessed luminaire)
