TRILUX Outdoor Luminaire Configurator

Simple calculation of streets and paths

The TRILUX Outdoor Luminaire Configurator is your quick and easy online aid in the search for the right street and path lighting: you enter a few parameters and the outdoor luminaire configurator calculates the suitable luminaires for you (including project-specific luminous intensity distribution curves, luminous flux and most effective lenses).

You receive the right solution directly from the entire TRILUX streetlighting portfolio.

From existing luminaires with fixed luminaire spacing to new luminaires taking into account the DIN EN 13201 road standard, the 12464-2 or self-selectable quality features, the configurator finds the ideal TRILUX luminaire for you - quickly and simply ala Simplify Your Light!

To the luminaire configurator



For streets

For footpaths and cycle paths

Advantages of the outdoor luminaire configurator

Short waiting time

No installation

Lens selection

PDF export

Visualisation of the street scene

Determination of number of units

Luminous flux selection

Exclusive service

What can the Outdoor Luminaire Configurator do?

Street geometries

The street quick planner includes the following street geometries:

• Street width = 4m - 10m (0.5m steps)
• Pole height = 3m - 12m (0.5m steps)
• Slope = 0° - 15° (5° steps)
• Light point overhang = - 2m to + 2m (0,5m steps)
• Light point spacing = 20m - 80m (1m steps)



Pavement geometries

The street quick planner includes the following pavement geometries:

• Pavement width = 1m - 4m (0.5m steps)
• Pole height = 2m - 6m (0.5m steps)
• Slope = 0° - 15° (5° steps)
• Light point overhang = - 2m to + 1m (0,5m steps)
• Light point distance = 1m - 60m (1m steps)

Luminaires

• LIQ 50/70/90
• Cuvia 40/60
• Lumega 600/700
• Viatana & Viatana P
• Convia
• Publisca
• 9301 K
• 98er series (9811,9821,9831,9851)
• ViaCon
• 8841 Bollard series
• 8841LS

Lenses / Reflectors

• AB2L                          AB2R
• AB5L                          AB7R
• AB6L
• AB7L
• AB8L
• AB14L
• SB3L

Screenshots
