Switch now. Save energy.
ARE YOU READY FOR A TECHNOLOGY SHIFT?
Quality of light, energy efficiency and sustainability: those who refurbish their lighting now invest in more well-being, greater safety and higher quality of life. In every application, TRILUX accompanies you through the entire process, from office to logistics, indoor and outdoor. Find out how you can benefit from a new lighting system, and why retrofitting is not necessarily a sustainable solution for your LED refurbishment. Find out why you shouldn’t wait any longer with your LED refurbishment – SWITCH NOW. SAVE ENERGY.
With an LED refurbishment you can achieve up to 85% in energy savings and improve the quality of light. Intelligent light management provides flexibility for the future. Efficient lighting solutions amortise in a short time.
Refurbish now and save!
Nothing to give away? Cut energy costs by up to 85 percent!
€
Net savings per year
Energy price
Calculation example: Production hall at TRILUX in Arnsberg with approx. 2,000 m² with a previous stock of 328 E-Line luminaires T8, 1 x 58W, VVG (21,648 W), which were replaced by E-Line Next Active luminaires, 6,000 lm, 39 W (12,792 W). In line with Human Centric Lighting (HCL), the new lighting system enables the colour temperature to be adapted to the course of the day of natural light (circadian progression) and an increased lighting level to be set if required.
The adjacent calculation is based on 4,000 operating hours per year, with controlled operation at 500 lx. The maximum available illuminance of 880 lx can be called up as required.
€ per kWh
Compare
€
Net savings per year
Energy price
Calculation example: Office with approx. 120 m2 with 18 T8 louvre lights, 4x18W, VVG (1,512 W) replaced by 18 Creavo M84 lights, 4,200 lm, 25 W (450W). 2,750 operating hours annually. Additional savings through daylight-dependent control: 55%.
€ per kWh
Compare
€
Net savings per year
Energy price
Calculation example: 120 continuous-row gear trays, T8, 1 x 58W, VVG (7,920W), replaced by 120 78IP50HE LDAN 40 gear trays (2,640 W), 216 HIT 35 W spotlights (9,288 W), replaced by 216 Canilo 3,000 lm LED spotlights (4.104 W). 3,600 operating hours per year.
€ per kWh
Compare
€
Net savings per year
Energy price
Calculation example: Classroom with 10 T8 louvre luminaires, 1 x 58W, VVG (660 W), replaced by 8 OPENDOACT D2 luminaires, 4200 lm and 2 OPENDO D2 blackboard luminaires, 5900 lm (264 W + 70 W). 1,400 operating hours per year. Additional savings through presence detection and daylight-dependent control: 65%.
€ per kWh
Compare
€
Net savings per year
Energy price
Calculation example: Parking lot with 20 post-top luminaires, HIT 150W (3,260 W) replaced by 20 JOVIE70 post-top luminaires, 7,500 lm (1,340 W). 2,000 operating hours per year.
€ per kWh
Compare
€
Net savings per year
Energy price
Calculation example: Corridor areas of a care home with 130 diffuser luminaires 3331W, 1 x T5 35W (5,070 W), each retrofitted with an LEDKIT 3331 D3 (2,600 W). 8,760 operating hours per year. Additional savings through presence detection reduced night light: 40%.
€ per kWh
Compare
Need help with your lighting refurbishment?
References
Why does a refurbishment with LED worthwhile?
Energy costs, lamp ban & sustainability
New rules of the game due to lamp bans
EU regulations on energy efficiency (the Ecodesign Directive) and the use of mercury in light sources (RoHS Directive) make refurbishment with LED luminaires unavoidable in the long term. The following light sources may no longer be placed on the market from 2023:
No longer on sale since 25 February 2023
Compact fluorescent lamps without integrated control gear unit
Ring-shaped fluorescent lamps, T5
No longer on sale since 25 August 2023
Tubular T5 fluorescent lamps
Tubular T8 fluorescent lamps
Retro Fit vs. 1:1 Exchange
Fluorescent lamp out, retrofit-solution in, done?
In theory, retrofit conversion is quick and easy. In practice, however, the effort involved is often underestimated.
Cutting costs with LED refurbishment
The LED refurbishment of lighting systems can be an effective way to save energy and upgrade to state-of-the-art technology. Modern LED lighting technologies allow you to significantly reduce energy consumption and improve the quality of light at the same time.
TRILUX offers the following LED refurbishment options which also simplify your building-specific planning:
1. New lighting concept based on all building-specific requirements
2. Direct replacement of old luminaires for economical LED luminaires
3. Design of customised solutions in line with heritage building or health protection requirements
New system
New design based on building-specific requirements with professional lighting design and light management.
1:1 replacement
Replacement of existing old luminaires for professional LED luminaires at a ratio of 1:1.
What do I use for the refurbishment project?
Just a few steps to the right LED luminaire for a 1:1 refurbishment
With our intelligent online refurbishment wizard you can find the right replacement product for your outdated conventional lighting in just a few steps. Even if you don't have all the data at hand, the tool guides you through the selection process. Why not give it a try right now?
The ideal refurbishment solution identified in next to no time.
The right contact for any
refurbishment project
Whether indoor or outdoor, office or industry – we look forward to your questions.
